QUESTION 51
Refer to the exhibit.

Which two statements are true of the interfaces on Switch1? (Choose two.)
A. Multiple devices are connected directly to FastEthernet0/1.
B. A hub is connected directly to FastEthernet0/5.
C. FastEthernet0/1 is connected to a host with multiple network interface cards.
D. FastEthernet0/5 has statically assigned MAC addresses.
E. FastEthernet0/1 is configured as a trunk link.
F. Interface FastEthernet0/2 has been disabled.

Correct Answer: BE
QUESTION 52
Three switches are connected to one another via trunk ports. Assuming the default switch configuration, which switch is elected as the root bridge for the spanning-tree instance of VLAN 1?
“Pass Any Exam. Any Time.” – www.actualtests.com 38 Cisco 200-120 Exam
A. the switch with the highest MAC address
B. the switch with the lowest MAC address
C. the switch with the highest IP address
D. the switch with the lowest IP address
Correct Answer: B
QUESTION 53
What are three advantages of VLANs? (Choose three.)
A. VLANs establish broadcast domains in switched networks.
B. VLANs utilize packet filtering to enhance network security.
C. VLANs provide a method of conserving IP addresses in large networks.
D. VLANs provide a low-latency internetworking alternative to routed networks.
E. VLANs allow access to network services based on department, not physical location.
F. VLANs can greatly simplify adding, moving, or changing hosts on the network.

Correct Answer: AEF
QUESTION 54
Refer to the exhibit.

C-router is to be used as a “router-on-a-stick” to route between the VLANs. All the interfaces have been properly configured and IP routing is operational. The hosts in the VLANs have been configured with the appropriate default gateway. What is true about this configuration?
A. These commands need to be added to the configuration: C-router(config)# router eigrp 123 C-router(config-router)# network 172.19.0.0
B. These commands need to be added to the configuration: C-router(config)# router ospf 1 C-router(config-router)# network 172.19.0.0 0.0.3.255 area 0
C. These commands need to be added to the configuration: C-router(config)# router rip C-router(config-router)# network 172.19.0.0
D. No further routing configuration is required.

Correct Answer: D
QUESTION 55
VLAN 3 is not yet configured on your switch. What happens if you set the switchport access vlan 3 command in interface configuration mode?
A. The command is rejected.
B. The port turns amber.
C. The command is accepted and the respective VLAN is added to vlan.dat.
D. The command is accepted and you must configure the VLAN manually.
Correct Answer: C
QUESTION 56
Refer to the exhibit.
“Pass Any Exam. Any Time.” – www.actualtests.com 88 Cisco 200-120 Exam

A technician is troubleshooting host connectivity issues on the switches. The hosts in VLANs 10 and 15 on Sw11 are unable to communicate with hosts in the same VLANs on Sw12. Hosts in the Admin VLAN are able to communicate. The port-to-VLAN assignments are identical on the two switches. What could be the problem?
A. The Fa0/1 port is not operational on one of the switches.
B. The link connecting the switches has not been configured as a trunk.
C. At least one port needs to be configured in VLAN 1 for VLANs 10 and 15 to be able to communicate.
D. Port FastEthernet 0/1 needs to be configured as an access link on both switches.
E. A router is required for hosts on SW11 in VLANs 10 and 15 to communicate with hosts in the same VLAN on Sw12.

Correct Answer: B
QUESTION 57
Refer to the exhibit.
“Pass Any Exam. Any Time.” – www.actualtests.com 89 Cisco 200-120 Exam Given this output for SwitchC, what should the network administrator’s next action be?

A. Check the trunk encapsulation mode for SwitchC’s fa0/1 port.
B. Check the duplex mode for SwitchC’s fa0/1 port.
C. Check the duplex mode for SwitchA’s fa0/2 port.
D. Check the trunk encapsulation mode for SwitchA’s fa0/2 port.

Correct Answer: C QUESTION 58
In which circumstance are multiple copies of the same unicast frame likely to be transmitted in a
“Pass Any Exam. Any Time.” – www.actualtests.com 92 Cisco 200-120 Exam switched LAN?
A. during high traffic periods
B. after broken links are re-established
C. when upper-layer protocols require high reliability
D. in an improperly implemented redundant topology
E. when a dual ring topology is in use

Correct Answer: D QUESTION 59
Refer to the exhibit.

What commands must be configured on the 2950 switch and the router to allow communication between host 1 and host 2? (Choose two.)
A. Router(config)# interface fastethernet 0/0 Router(config-if)# ip address 192.168.1.1 255.255.255.0 Router(config-if)# no shut down
B. Router(config)# interface fastethernet 0/0 Router(config-if)# no shut down Router(config)# interface fastethernet 0/0.1 Router(config-subif)# encapsulation dot1q 10 Router(config-subif)# ip address 192.168.10.1 255.255.255.0 Router(config)# interface fastethernet 0/0.2 “Pass Any Exam. Any Time.” – www.actualtests.com 66 Cisco 200-120 Exam Router(config-subif)# encapsulation dot1q 20 Router(config-subif)# ip address 192.168.20.1 255.255.255.0
C. Router(config)# router eigrp 100 Router(config-router)# network 192.168.10.0 Router(config-router)# network 192.168.20.0
D. Switch1(config)# vlan database Switch1(config-vlan)# vtp domain XYZ Switch1(config-vlan)# vtp server
E. Switch1(config)# interface fastethernet 0/1 Switch1(config-if)# switchport mode trunk
F. Switch1(config)# interface vlan 1 Switch1(config-if)# ip default-gateway 192.168.1.1

Correct Answer: BE
QUESTION 60
Cisco Catalyst switches CAT1 and CAT2 have a connection between them using ports FA0/13. An 802.1Q trunk is configured between the two switches. On CAT1, VLAN 10 is chosen as native, but on CAT2 the native VLAN is not specified.
What will happen in this scenario?
A. 802.1Q giants frames could saturate the link.
B. VLAN 10 on CAT1 and VLAN 1 on CAT2 will send untagged frames.
C. A native VLAN mismatch error message will appear.
D. VLAN 10 on CAT1 and VLAN 1 on CAT2 will send tagged frames.

Correct Answer: C



pdfdown



QUESTION 61
Which Cisco Catalyst feature automatically disables the port in an operational PortFast upon receipt of a BPDU?
A. BackboneFast
B. UplinkFast
C. Root Guard
D. BPDU Guard
E. BPDU Filter

Correct Answer: D QUESTION 62
A router has two Fast Ethernet interfaces and needs to connect to four VLANs in the local
“Pass Any Exam. Any Time.” – www.actualtests.com 82 Cisco 200-120 Exam network. How can you accomplish this task, using the fewest physical interfaces and without decreasing network performance?
A. Use a hub to connect the four VLANS with a Fast Ethernet interface on the router.
B. Add a second router to handle the VLAN traffic.
C. Add two more Fast Ethernet interfaces.
D. Implement a router-on-a-stick configuration.

Correct Answer: D
